Switching power supply for LED lighting systems IP67 HLG-120H-12A Mean Well
Switching power supply for LED lighting systems HLG-120H-12A Mean Well
Technical data:
- Model - HLG-120H-12
- Output voltage 10.8 ... 13.5V DC, 12V DC
- Output current 5 ... 10A
- Power 120W
- +/- 2.5% tolerance
- Interference 150mV
- Efficiency 92%
- Cable length 300mm
- Dimensions 220 x 68 x 38.8mm
Specification:
- supply voltage: 90-305VAC; 127-431VDC
- hermetic metal housing in accordance with the IP67 / IP65 standard
- built-in active PFC function
- 4KV surge immunity in accordance with IEC61000-4-5
- short circuit, overcurrent, overvoltage and thermal protection
- regulation of the output voltage with a potentiometer in version A
- regulation of the output current with a potentiometer A
- 3in1 dimming function in B version models (1 ~ 10VDC, PWM, resistor)
- cooling with open air circulation
- working temperature -40 ~ + 70 ° C
- compliance with a number of standards and certificates
- 5-year warranty
