DIN rail power supply slim 12V 6,3A 75,6W MEAN WELL | NDR-75-12
DIN rail power supply slim 12V 6,3A 75,6W MEAN WELL | NDR-75-12
The NDR series power supply is an economical version of slim DIN-rail power supplies. The power supply meets the strictest standards and criteria, making it suitable for use in industrial automation systems, machine control, lighting power supply.
SPECIFICATION:
- supply voltage: 90~264VAC, 124~370VDC
- output voltage: 12 VDC
- output voltage range: 12-14 VDC
- output current: 6.3A
- power: 75,6W
- efficiency 85,5%
- protections: short circuit, overload, overvoltage, thermal protection
- LED operation signaling
- DC relay connector OK
- cooling with open air circulation
- working temperature -20~+70°C
- mounting on DIN rail TS35 / 7.5 or 15
- compliance with the EN61000-6-2 (EN50082-2) standard
- dimensions: 125,2x102x35mm
The power supply is cooled by free air flow, making it highly trouble-free - a very important feature when the power supply is running continuously. The operating temperature for this model is from -20 to +70º. In addition, the power supply has overload protection of 105-160% of nominal power.
To download
Brand
Symbol
NDR-75-12
Producer code
5904139600375
Series
input voltage AC
90-264VAC
output voltage DC (V)
12V
DC adjustment range
12~14V
output current (A)
6,3A
power (W)
75,6W
efficiency
85,5%
mains frequency range
47/63Hz
permissible temperature range
-20º~+70ºC
IP rating
IP20
enclosure
metalowa
dimensons
125,2x102x35mm
weight
475g
