DIN rail buffer power pack 480W 48V 10A DRS-480-48

DIN rail buffer power pack 480W 48V 10A DRS-480-48

1 209,99 PLN
incl. VAT / pcs
Lowest price in 30 days before discount: / pcs
Regular price: / pcs
of
You can also buy using:
28 days for free returns
This product is not available in a stationary store
Safe shopping

SPECIFICATIONS:

  • input voltage 90-305VAC, 127-431VDC
  • output voltage: 48 V
  • rated current: 10 A
  • Rated output power: 480 W
  • efficiency: 93.5
  • regulation of the charging current in the range 20-100% of the nominal value
  • choice of 2-stage or 3-stage charging curve
  • Programmable charging parameters (for CANBus versions)
  • Built-in MODBus communication protocol
  • relay output: AC OK, DC OK, CHARGER FAIL, BATTERY LOW
  • open-air cooling
  • Suitable for lithium-ion and acid batteries
  • operating temperature from -30~+70°C
  • LED operation indication
  • compliance with many standards and certificates
  • wymiary: 110x125.2x150.7mm
Symbol
DRS-480-48
input voltage AC
90-305VAC
output voltage DC (V)
48V
output current (A)
10A
power (W)
480W
efficiency
93,5%
mains frequency range
50/60Hz
permissible temperature range
-30°~+70°C
enclosure
tworzywo ABS
dimensons
110x125.2x150.7mm
