Power supply with DALI interface for LED lighting 12V 5A 60W KNX Mean Well PWM-60-12KN
Power supply with DALI interface for LED lighting 12V 5A 60W KNX Mean Well PWM-60-12KN
Specification:
- version with DALI interface
- output voltage: 12V DC
- output current: 5A
- power: 60W
- efficiency: 86%
- cable length: 300mm
- wymiary: 150x53x35mm
- wide supply voltage range: 90~305VAC, 127~431VDC
- IP67-compliant sealed plastic housing
- constant output voltage independent of the load
- short-circuit, overload, overvoltage, thermal protection
- no-load power consumption <0,5W
- active PFC
- Class II insulation
- 3-in-1 dimming function (0~10VDC, PWM, resistance)
- open-air cooling
- operating temperature from -40 to +70°C
- compliance with a range of standards and certifications
To download
Brand
Entity responsible for this product in the EU
MEAN WELL EUROPE N.V.More
Address:
Langs de Werf 8Postal code: 1185XTCity: AmstelveenCountry: HolandiaPhone number: +31-20-758-6000E-mail: info@meanwell.eu
Symbol
PWM-60-12KN
Series
input voltage AC
90-305VAC
output voltage DC (V)
12V
output current (A)
5A
power (W)
60W
efficiency
86%
mains frequency range
50/60Hz
permissible temperature range
-40°~+70°C
IP rating
IP67
enclosure
ABS plastic
dimensons
150x53x35mm
weight
791g
