Power supply with DALI2 interface for LED lighting 24V 3.75A 90W Mean Well PWM-90-24DA2

Power supply with DALI2 interface for LED lighting 24V 3.75A 90W Mean Well PWM-90-24DA2

+ Add to compareAdd to shopping list
Size
uniwersalny
243,99 PLN
incl. VAT / pcs
Lowest price in 30 days before discount: / pcs
Regular price: / pcs
of
You can also buy using:
Free and fast delivery
28 days for free returns
Find out in which store you can check the product and buy it right away
Power supply with DALI2 interface for LED lighting 24V 3.75A 90W Mean Well PWM-90-24DA2
Power supply with DALI2 interface for LED lighting 24V 3.75A 90W Mean Well PWM-90-24DA2
uniwersalny
Safe shopping
Deferred Payments. Buy now, pay later, if you don't return it
Buy now, pay later - 4 steps
When choosing a payment method, select PayPo.PayPo - buy now, pay later
PayPo will pay your bill in the store.
On the PayPo website, verify your information and enter your social security number.
After receiving your purchase, you decide what suits you and what doesn't. You can return part or all of your order - then the amount payable to PayPo will also be reduced.
Within 30 days of purchase, you pay PayPo for your purchases at no additional cost. If you wish, you spread your payment over installments.

Specification:

  • version with DALI2 interface
  • output voltage: 24V DC
  • output current: 3,75A
  • power: 90W
  • efficiency: 90.5%
  • cable length: 300mm
  • wymiary: 150x53x35mm
  • wide supply voltage range: 90~305VAC, 127~431VDC
  • IP67-compliant sealed plastic housing
  • constant output voltage independent of the load
  • short-circuit, overload, overvoltage, thermal protection
  • no-load power consumption <0,5W
  • active PFC
  • Class II insulation
  • 3-in-1 dimming function (0~10VDC, PWM, resistance)
  • open-air cooling
  • operating temperature from -40 to +70°C
  • compliance with a range of standards and certifications
To download
Brand
MEAN WELL
Symbol
PWM-90-24DA2
Series
PWM
input voltage AC
90-305VAC
output voltage DC (V)
24V
output current (A)
3,75A
power (W)
90W
efficiency
90%
mains frequency range
50/60Hz
permissible temperature range
-40°~+70°C
IP rating
IP67
enclosure
ABS plastic
dimensons
150x53x35mm
weight
1030g
