LED lighting power supply flat 24V 0.25A 6W YINGJIAO | YSL12M-2400250
LED lighting power supply flat 24V 0.25A 6W YINGJIAO | YSL12M-2400250
LED lighting power supply flat 24V 0.25A 6W YINGJIAO | YSL12M-2400250
LED lighting power supply flat 24V 0.25A 6W YINGJIAO | YSL12M-2400250

LED lighting power supply flat 24V 0.25A 6W YINGJIAO | YSL12M-2400250

31,99 PLN
incl. VAT / pcs
Lowest price in 30 days before discount: / pcs
Regular price: / pcs
of
You can also buy using:
28 days for free returns
This product is not available in a stationary store
Safe shopping
Free delivery to parcel machinesMore information
Smile - deliveries from online stores when ordered from 50,00 PLN are for free.
You buy and delivery is free!
deliveries from online stores are free when you order 50,00 PLN are for free.
Free delivery includes parcel delivery to a parcel machine

YSL-T power supplies are high-performance constant-voltage (CV) output units for LED applications. Their special feature is the elongated housing design, which is both slim and low. Within the series, versions are available with 12 and 24 V output voltages and output powers from 15 to 100 watts. The power supplies operate with an input voltage of 220-240VAC and have an integrated active PFC equalizer.



SPECIFICATIONS:

  • input voltage range 200-240VAC
  • Frequency range of mains supply voltage:  50/60 Hz
  • Rated output voltage: 24 V
  • Rated output power: 6 W
  • rated load current 0,25 A
  • max. output voltage ripple 240mVp-p
  • energy conversion efficiency:  greater than 88%
  • output protection:  overcurrent protection  (OCP), short circuit protection  (SCP), overvoltage protection  (OVP)
  • input protection:  overvoltage (OVP), undervoltage (UVP)
  • protection against overheating
  • works with a dimmer
  • dimensions: 132x52x12 mm
  • weight: 150 g



CHARACTERISTICS:

  • elongated flat and narrow housing
  • high energy conversion efficiency
  • low starting current
  • low ripple and excellent stabilisation
  • wide operating temperature range -20 ... +50ºC.
  • easy-to-fit housing
  • fully protected electronics
  • compliance with international standards



APPLICATIONS:

  • building lighting systems
  • illuminated advertising
  • decorative lighting
  • industrial lighting
To download
Symbol
YSL12M-2400250
Producer code
5904139607053
Series
input voltage AC
200-240VAC
output voltage DC (V)
24V
output current (A)
0,25A
power (W)
6W
efficiency
88%
mains frequency range
50/60Hz
permissible temperature range
-20º~+50ºC
IP rating
IP44
enclosure
tworzywo ABS
dimensons
132x52x12mm
weight
150g
